Electrical Hydraulic Knuckle Boom Crane Marine Crane with ABS BV CCS CE Certification
Application
1. Maritime Operations: Ideal for a variety of maritime applications, these cranes are crucial for cargo handling on ships. Whether it's loading and unloading goods at ports or moving equipment between decks, their flexibility and precision ensure smooth operations.
2. Offshore Industry: In the offshore industry, Maxtech cranes are used for tasks like lifting and positioning equipment on oil rigs. Their ability to withstand extreme temperatures makes them reliable in harsh offshore environments.
3. Coastal and Island Operations: For coastal and island - based operations, such as transporting supplies or construction materials, these cranes provide an efficient and safe solution.
Model Ranges
Maxtech offers a wide range of models.
1. The lifting capacity varies from 5000 kg to 30 tons for heavy - duty operations, such as loading large containers.
2. The working radius, from 2.5 meters for close - range operations to 28 meters for more extensive reach, allows for adaptability in different working scenarios.
| Main Specification | |||||
| Safety Load | Max Outreach | Lifting Speed | Slewing Speed | Luffing Time | Hoisting Height |
| kN | m | m/min | m/min | s | m |
| 10 | 6-20 | 15 | 1 | 60 | 30 |
| 15 | 8-22 | 15 | 1 | 60 | 30 |
| 20 | 5-24 | 15 | 1 | 60 | 30 |
| 30 | 8-25 | 15 | 0.9 | 70 | 30 |
| 50 | 12-25 | 15 | 0.75 | 80 | 30 |
| 80 | 12-25 | 15 | 0.75 | 100 | 40 |
| 100 | 12-25 | 15 | 0.75 | 110 | 40 |
| Above specifications only for reference, We can supply various marine cranes according to your requirements. | |||||
Features
1. Certified Quality: The ABS, BV, CCS, and CE certificates are a testament to the high - quality manufacturing and design of these cranes.
2. Marine - Specific Design: Special coating treatments and stainless - steel key parts protect against corrosion, ensuring a long service life in the marine environment.
3. Temperature Adaptability: The ability to operate in extreme temperatures makes them suitable for diverse geographical locations and harsh working conditions.
4. Reliable Hydraulic System: Developed in collaboration with hydraulic experts, the crane's hydraulic system, equipped with safety monitors for pumps and brakes, guarantees reliable and safe operation.
5. Space - Saving Design: The compact and lightweight knuckle/folding booms optimize vessel space and reduce load, enhancing overall efficiency.
Maxtech is committed to providing trouble - free cranes. Contact us for a free quotation and experience our top - notch products and services.
Industry Certifications
1. Quality certificates and factory test reports are provided to provide strong evidence for product quality and allow users to use the product with confidence.Safety Certifications: CE (European Union), ISO 9001(International Organization for Standardization)
2. We have established cooperative relationships with several renowned enterprises that hold leading positions in their respective fields.
Maxtech is committed to providing trouble - free cranes. Contact us for a free quotation and experience our top - notch products and services.
